Integration and Operation of an Advanced Weigh-in-Motion (A-WIM) System for Autonomous Enforcement of Overweight Trucks

Overview

Roadways in New York City handle substantial daily traffic throughout different boroughs. Trucks have been an integral part of the freight movement network in distributing goods and services to various communities; however, a percentage of these trucks are often overloaded beyond legal load limits. The Brooklyn-Queens Expressway (BQE) that connects two boroughs suffers from significant deterioration because of the existing environmental conditions exacerbated by a substantial number of OW trucks.

The New York City Department of Transportation (NYCDOT) has been planning to rehabilitate the bridge to accommodate future traffic volume and weight demands. Accordingly, the team closely worked with the NYCDOT and collected truck traffic and weight data to provide recommendations for future design or rehabilitation work on BQE bridges. The team learned that the average daily number of OW trucks is significantly higher, and the extent of the OW (or OW tonnage) is substantially heavier than the national average.

Our team also found that current OW enforcement practices at the weighing stations and by the weight enforcement officers using portable scales would capture only a small fraction of the OW trucks.  For example, the number of vehicles screened by four weighing stations in NJ was 1,006,749 in 2009, and only 0.142% (1,430 trucks) of screened trucks were overweighted and ticketed.  However, the actual OW percentage along the corridors near four weighing stations in NJ was 6.4%, based on the WIM data.  This confirms that the current OW enforcement practices would only capture less than 3% of total OW trucks. Therefore, a more practical and efficient OW enforcement scheme would be needed to discourage the trucking industry from overloading their fleets.

Research Objectives

The ultimate objective of this project is to assist and support the NYCDOT in establishing the legislation to operate the autonomous OW enforcement system and extend the service life of the BQE corridor. The team will utilize two testbeds on both sides of the BQE corridor to develop the guidelines and specifications for the operation of the OW enforcement system in an urban area.  The deliverables will include, but not be limited to, an updated NYCDOT in-house calibration procedure and methodology to assure weight accuracy, the attainable accuracy target under current roadway conditions, and updates of service life predictions for BQE bridges.

The scope of work will include the following tasks:

Task 1 – Establishment of a new smart roadway testbed at the south part of the BQE corridor

Task 2 – Implementation of automated license plate recognition (ALPR) system and other available technologies

Task 3 – Practice of autonomous enforcement

Task 4 – Evaluation of the impact of OW truck enforcement on load rating and reliability assessment of BQE structure

Task 5 – Technical support to establish the legislation for the operation of the autonomous enforcement at BQE

Deliverables include the final report and technical memorandum(s) for the new smart roadway testbed on BQE, deployment of SW-based ALPR system, etc.

Personnel

Kaan Ozbay

Director of the C2SMART Center

Kaan Ozbay is a Co-Principal Investigator on this project.

Chaekuk Na

Senior Research Associate at Rutgers

Chaekuk Na is a Co-Principal Investigator on this project.

Hani Nassif

Associate Director for Outreach and Technology Transfer

Hani Nassif is a Principal Investigator on this project.

Peng Lou

Research Associate in the Department of Civil and Environmental Engineering at Rutgers

Peng Lou is a Co-Principal Investigator on this project.

Thales Couto Braguim

PhD candidate at Rutgers University

Thales Couto Braguim is a Student Researcher on this project.
